10. Real-time transmission over UTP Cat5e/6
Specification:
Model |
CPB-H221C |
Balun Type |
Passive |
Video transmitting distance |
Up to 450m for 720P CVI Cameras |
Video Formats |
NTSC, PAL, SECAM |
Crosstalk & noise immunity |
60dB |
Surge protection |
4KV, ESD:8KV |
Frequency Response |
DC to 60Mhz |
Wire Type |
Unshielded Cat-5 or above twisted pair wire |
Impedance |
BNC:75 ohms; Terminal: 100 ohms |
Working temperature |
-10°C to +70°C |
Storage Temperature |
-10°C to +70°C |
Humidity |
0 to 95% |
Material |
ABS engineering plastic |
